Value Adjust (Balance,Contrast,Brightness)


  • Where to find it:


    • Add Adjustment Layer / Extension Pack / Histogram /


    • NodeGraph / Right Mouse Click / Nodes / Filter / Extension Pack / Histogram /





The Value Adjust Node (Balance,Contrast,Brightness) houses commonly used operations in a single node



Video



Node Overview



Node Ports


  • Input

The input texture to change


  • Balance

Adjusts the Balance of the Input Texture. Replaces the Slider value if mapped


  • Contrast

Adjusts the Contrast of the Input Texture. Replaces the Slider value if mapped


  • Brightness

Adjusts the Brightness of the Input Texture. Replaces the Slider value if mapped

Node Properties


MAIN TAB

Main


  • Balance

Adjust the Balance of the Input Texture


  • Contrast

Adjust the Contrast of the Input Texture.


A default contrast midpoint of 0.5 is used.


  • Brightness

Adjust the Brightness of the Input Texture.

The algorithm used depends on the Brightness Mode


  • Invert

Invert the corrected result


Clamp


  • Clamp Output

Clamp the Output of this Node


  • Min

The Minimum value to clamp to


  • Max

The Maximum value to clamp to



Extra Attributes


  • Traditional Brightness Mode


Turning the Traditional Brightness Mode on, will switch the Brightness Calculation to the the algorithm commonly used inside of Mari to adjust Brightness.



    • Left Side:Traditional Brightness OFF
    • Right Side : Traditional Brightness ON
    • Stepping through values from -1 to 1 in 0.1 incremented
